70W Pedestrian Barrier Gate Automatic Systems Turnstiles Fingerprint Control

Product Description:0.6s Opening Speed RFID Card Reader Pedestrian Turnstile Gate For Commercial Building

Our Pedestrian Barrier Gate is a security personnel traffic turnstile gate designed to control and manage pedestrian access. It is an ideal pedestrian control turnstile for areas requiring high levels of security, such as office buildings, industrial complexes, data centers, etc. Featuring a compact design and robust construction, this turnstile gate is sure to provide reliable and effective pedestrian access control. It is equipped with a powerful motor to ensure a smooth operation, and features a low power consumption. The opening speed is 0.6 seconds, and the closing angle is 90°. The size of the gate is 1400MM*160MM*980MM, and the weight is 65kg. The voltage is 220V.



Features:

• Product Name: Pedestrian Barrier Gate
• Material: Stainless Steel 304
• Access Control: Fingerprint, IC Card
• Power: 70W
• Communication Interface: RS485
• Security: Pedestrian Control Turnstile
• Safety: Pedestrian Access Control Turnstile

Physical size (mm):	1400 (length) × 160 (width) × 980 (height) can be customized
Cabinet material:	SUS304 stainless steel, surface drawing treatment
Material thickness (mm):	1.5
Passage width (mm):	600 (standard), 700 (wide passage)
Gate wing material:	Plexiglass
Gate wing size (mm):	280 (length) × 550 (width) × 8 (thickness)
Response time of gate opening and closing:	<0.1 second
Gate wing running speed:	≥ Rad/s (adjustable)
Average number of failure-free operations:	5 million times
Passage target detection:	4 groups of infrared beams
Passing speed:	≥50 people/min (normally closed mode)
Application environment:	indoor/outdoor
Working temperature:	-30℃～60℃
Working humidity:	≤90%, no condensation
Power supply:	AC220V±, 50Hz
Average power consumption (W):	60























Applications:

The Pedestrian Barrier Gate provided by Zecheng has all the features that you need for a reliable pedestrian access control turnstile. The model number is ZC-S103, and it comes with a minimum order quantity of 2 sets. It is made of durable stainless steel 304 material and is supplied with a powerful 70W power. It has a size of 1400MM*160MM*980MM and its opening speed is 0.6s. This product is manufactured in China and comes with different packaging options including carton and wooden boxes. It has a fast delivery time of 7 days and has a supply ability of 1000 sets per month. This pedestrian safety access control turnstile is perfect to be used for crowd control turnstile gates.

Customization:

Pedestrian Barrier Gate

Brand Name: Zecheng
Model Number: ZC-S103
Place of Origin: China
Minimum Order Quantity: 2 sets
Packaging Details: Carton and wooden box packaging
Delivery Time: 7days
Supply Ability: 1000 sets per month
Weight: 65kg
Product Name: Pedestrian Barrier Gate
Material: Stainless Steel 304
Closing Speed: 0.6s
Communication Interface: RS485

Our pedestrian barrier gate is designed for pedestrian safety access control turnstile and security pedestrian control turnstile. It is made of high-quality stainless steel 304 material, with a weight of 65kg. It has a closing speed of 0.6s and a communication interface of RS485. You can purchase a minimum order quantity of 2 sets with quick delivery time of 7days. We can supply up to 1000 sets per month with carton and wooden box packaging.



Support and Services:

• 24/7 technical support
• Onsite installation and commissioning
• Regular maintenance and troubleshooting
• Online remote assistance
• Warranty for parts and services
• Service level agreement



Packing and Shipping:

The Pedestrian Barrier Gate will be securely packaged, wrapped, and shipped to the customer's desired location. Upon delivery, the customer will receive the gate in a box with instructions on how to assemble and install it.

The box will include all necessary hardware and components needed to attach the gate to the mounting surface. All components will be well-secured in the box to prevent possible damage during transportation.

If needed, we can also provide installation and assembly services for the customer upon request. Please contact us for more details.



FAQ:

A1. The Brand Name of the Pedestrian Barrier Gate is Zecheng. A2. The Model Number of the Pedestrian Barrier Gate is ZC-S103. A3. The Pedestrian Barrier Gate is from China. A4. The Minimum Order Quantity of the Pedestrian Barrier Gate is 2 sets. A5. The Delivery Time of the Pedestrian Barrier Gate is 7 days.
